Home News GD100HFY120C1S IGBT module: an efficient solution for advancing power electronics

In the field of modern power electronics, IGBT (Insulated Gate Bipolar Transistor) modules are widely used in a variety of high-power devices due to their high performance and reliability.GD100HFY120C1S is a high-performance IGBT module launched by Starpower, designed to meet the needs of electric vehicles, industrial motor control, renewable energy and other fields. This article will be the product's main features, application scenarios and technical advantages are introduced in detail.Product Brochure


The GD100HFY120C1S IGBT module has the following notable features:

Rated voltage and current: the module has a rated voltage of 1200V and a rated current of 100A, which is suitable for high-voltage and high-current application scenarios.

Low Saturation Voltage: Using advanced Trench IGBT technology, the GD100HFY120C1S has a low VCE(sat), which means that the power consumption can be significantly reduced during switching operation, improving the overall efficiency of the system.

Short-circuit protection capability: With a 10μs short-circuit protection capability, this module is able to provide effective protection in short-circuit situations, ensuring the safety of equipment and systems.

High-temperature operation capability: The GD100HFY120C1S has a maximum junction temperature of up to 175°C, making it suitable for operation in high-temperature environments and ensuring its reliability under harsh conditions.

GD100HFY120C1S IGBT modules are widely used in many fields, mainly including:

Electric Vehicle Drive Systems: In electric vehicles, the modules are used to efficiently control electric motors, meeting high demands for power and efficiency.

Industrial Motor Control: Widely used in motor drive and control systems for a variety of industrial equipment, providing precise speed and torque control.

Uninterruptible Power Supply (UPS) : In a UPS system, the GD100HFY120C1S improves the stability and reliability of the power supply and ensures that power continues to be supplied in the event of a power failure.

Renewable Energy System : For example, in solar inverters, this module is used to convert DC power to AC power, improving the efficiency of energy conversion.

Inverters: In inverters, this module is used to regulate the operating speed and power of motors to improve energy efficiency.

The GD100HFY120C1S IGBT module has been designed with a variety of application requirements in mind and offers the following technical advantages:

High Efficiency: Low conduction loss and short-circuit capability allow it to excel in high-power applications and can effectively reduce energy consumption.

RELIABILITY: High temperature operating capability and short-circuit protection ensure the module's stability and safety under various operating conditions.

Flexibility: The module is suitable for a wide range of application scenarios and can meet the needs of different industries, with wide market adaptability.

Summary

The GD100HFY120C1S IGBT module is a high-performance power electronic component that has become an important part of electric vehicles, industrial motor control, renewable energy, and other fields thanks to its excellent technical characteristics and wide range of application scenarios. With the increasing global demand for efficient and reliable power solutions, the GD100HFY120C1S will continue to play a key role in driving the advancement of power electronics technology and application innovation.

UCC INDU, as a professional IC authorised distributor, is providing customers with the GD100HFY120C1S model as well as other products from Starpower. As a leader in the industry, UCC INDU provides customers with one-stop solutions for electronic components with its extensive product line and professional technical support. Whether you are looking for high performance IGBTs or need other electronic components, UCC INDU is your reliable partner. Welcome to visit the official website of UCC INDU to learn more about our products and get our attentive service.


Disclaimer: The information provided on this page is for informational purposes only. We do not warrant the accuracy or completeness of the information and accept no liability for any loss or damage arising from the use of such information.
